China 10km long range 4g wifi pressure sensor transmitter price

FOB Reference Price:Get Latest Price
$185.00 - $215.00 / Pieces | 1 Piece/Pieces (Min. Order)
Material:
Explosion-proof design and housing
Accuracy:
0.25%F.S
Type:
Wireless
Pressure Range:
-0.1~0...100MPa
Customization:
Customized logo (Min. Order: 1 Pieces)
Customized packaging (Min. Order: 1 Pieces)

More

Graphic customization (Min. Order: 1 Pieces) Less
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Shaanxi, China
Brand Name:
XINGYUTENG
Model Number:
QYB500
Name:
wireless pressure transmitter
Output signal:
4G/2G
Overload Capacity:
150%F.S.
Power Supply:
12~30VDC
Electronic Connecting:
Block Terminal
Protection grade:
IP65
Relative Humidity:
0~90%
Operating Temperature:
-30°C~80°C
Medium Temperature:
-40°C~150°C
Stability:
≤0.1%/year
Supply Ability
Supply Ability:
10000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
cartons packing and other
Port
shanghai,tianjin ,shenzhen and other
Product Description

China 10km long range 4g wifi pressure sensor transmitter price

Spe QYB500

Overview

QYB500 is a wireless pressure transmitter with low-power consumption. It adopts advanced industrial MCU core, high quality sensor, industrial wireless Zigbee data module, high-capacity lithium battery. It can realize the Zigbee internet system consist of multi products, monitoring the current data of multi points in wide range, such as gas chamber, oil tank and industry automation. It is used in petroleum, coal and water supply automation system.


Main Features

1.QYB500 suitable for four letter agreement, QYB501 suitable for A11 agreement
2.Wireless measurement in pipeline, specially used in pressure measurement of oilfield and wellhead
3.Explosion-proof design and housing, intrinsic safety in circuit
4.Protection grade IP67, fully sealed waterproof design
5.Zigbee communication, test and adjust by hand calibrator
6.LCD display, -40~70℃ wide working temperature range, display pressure data and battery voltage
7.38Ah high-capacity lithium battery, extended working life
8.High gain antenna, wireless transmission distance of 1000m



SPECIFICATIONS FOR QYB500 Wireless Pressure Transmitter
PRESSURE RANGE
-0.1~0...100MPa
ACCURACY
0.25%F.S
STABILITY
≤0.1%/year
POWER SUPPLY
12~30VDC
Overload Capacity
150%F.S.
Power Supply
3.6v lithium battery
Reporting period
1s~10hous
Display
LCD
Signal output
ZigBee
Transmitting power ratio
≤40mW
Communication distance
1000m
Explosive-proof grade
Exib IIB T6 Gb
Protection level of case
IP67
Process interface
Customized
Operating Temperature
-40-70℃
Relative Humidity
≤90%
Weight
2000g
About us

Baoji XingYuTeng Measure and Control Instruments Co., Ltd was founded in 2007, is located in Baoji, Shaanxi Province,China.
As a well-known manufacturer, XingYuTeng specializes in High-tech R&D, focuses on self-developing, manufacturing and selling of measurement and control products for pressure, temperature, liquid level and flow.
XingYuTeng can offer an extensive variety of the highest quality pressure transmitter as well as digital pressure gauge and level transmitter and temperature transmitter. Recognized for their accuracy and long-term reliability, our products are the sensor of choice for diverse markets such as hydroelectricity, public waterworks, chemical engineering,mechanical engineering, petroleum industry, Industrial Controls, Medical industry and Food Handling.

With the implementation of ISO9001, CMC (China Metrology Certification), EX(Explosion-proof certification),our company has adopted programs to ensure compliance with the necessary directives for quality control and product safety.
At present, our products have been accepted and exported to Europe, America, Southeast Asia, Africa and other regions all over the world. Based on the purpose of satisfying customers, we keep improving our product development capability and processing technic to offer a better product.

We sincerely hope that we can be one of your dependable and trust-able cooperators!
Exhibition


Application

Oil pumping/Oil drilling


Automobile


HVAC


Natural gas


CNG/LNG Gas station


Pump&water treatment


Hydraulic control system


Chemical industry


Food industry


Packing & Delivery

1.If the quantity of order is not very big, we could deliver them to you by express, such as TNT,DHL,UPS,FEDEX or EMS.

2.If order is big , we will advise you use Air shipping or Sea shipping through your nominated forwarder agent,our  long-term      cooperated agent is also available.

3.Freight collect if bulk shipment.

Certifications
FAQ new

1. How long will you reply me?
     Within 1 hour, no longer than 12 hours.
2. How can I get the quotation?
     Please advise the required specification including measuring range, electronic connection, output signal, thread

     connection, medium, shell material, operating temperaturer, etc, then we can recommend the suitable model for you.

3. Can I get sample?
     Pls contact with us online directly and then we can discuss case by case.
4. Can I visit your factory?
     Sure, you are always welcome, we are ORIGINAL MANUFACTURER.

     Our factory is located at Baoji city, Shaanxi province, China.
5. Can we use our logo on the products?
     Yes, we can offer the OEM/ODM service.
6. How long is your warranty period?
     Within 12 months from the receipt of goods
7. What is your terms of payment?
     T/T, L/C, Western union, PayPal, credit Assurance
